FuseBox INC202NC 20A 230V N/C 2 pole Contactor
The FuseBox INC202NC is a robust 20A 230V modular contactor designed for reliable switching and load control in industrial and commercial applications. This 2-pole normally closed contactor delivers consistent performance with a rated capacity of 20A (AC-7a) or 6.4A (AC-7b), making it suitable for a wide range of electrical circuits. Built for efficiency, the unit features minimal power consumption with holding VA of 2.7VA and inrush VA of 9.2VA, whilst dissipating just 1.2W during operation. The contactor accommodates cable sizes up to 4mm² and comes supplied with two 9mm heat dissipation spacers to optimise thermal management and extend operational life. Engineered to exacting standards, this FuseBox contactor offers dependable switching action and is backed by a 1-year warranty. Ideal for automation systems, motor control, and load management applications where precision and durabi…
Fiche technique
| Référence | INC202NC |
|---|---|
| Marque | Fusebox |
| Catégorie | Commande & sectionnement |
| Inrush VA | 9.2VA |
| Holding VA | 2.7VA |
| Caractéristique 1 | Rated at 20A (AC-7a) or 6.4A (AC-7b) |
| Caractéristique 2 | 2 Pole |
| Caractéristique 3 | Supplied with 2x9mm heat dissipation spacers |
| Caractéristique 4 | Normally Closed state configuration |
| Caractéristique 5 | 1 Year Warranty |
| Dissipated wattage | 1.2W |
| Maximum cable capacity | 4mm2 |
